Wharfedale DP 4065 – 4 Channel 1U Stereo Amp (4x 1870W RMS)

Name: Wharfedale DP 4065 – 4 Channel 1U Stereo Amp (4x 1870W RMS)
Brand: Wharfedale
SKU: XASH-WHARDP4065.
Price: 21645.00 ZAR
Availability: OutOfStock

SKU: XASH-WHARDP4065.

Original price was: R29,950.00.Current price is: R21,645.00.

Enquire for Availability & Updated Price

Notify me when the item is back in stock.

Your Product Page

Description
Tech Specs

DP-4065

Suitable for professional live sound reinforcement or fixed installations, the 4-channel DP-4065 delivers extreme power from a light weight box.

Its advanced switch mode power supply and super-efficient Class D topology delivers high power with low distortion.

With 4 discrete channels and multiple operating modes its simple to configure into the most complex of installations or touring rigs.

4 channels
8 Ohm 4 x 650 W
4 Ohm 4 x 1100 W
2 Ohm 4 x 1870 W
16 Ohm Bridged 2 x 1300 W
8 Ohm Bridged 2 x 2200 W
4 Ohm Bridged 2 x 3740 W
100 V Hi-Z : No
70 V Hi-Z 4 x 1100 W

DP-F Series

Huge Class D power in a 1U rack
4 discrete amplification channels
Internal DSP and computer control
Stable down to 2 Ω. Drive multiple speakers or line array elements
FIR filtering with 512 taps
90 V to 260 V AC working voltage
Ethernet Network Connectors x 2
70 V / 100 V compatible models

TAKE CONTROLHarnessing the power of the internal DSPThe supplied editing software gives a practical overview of all system parameters and DSP features within the DP-F amplifier.It is simple to monitor and edit the DP-F remotely.

FIR FILTERSFIR Filtering gives

Independent control of magnitude and phase.
More detailed equalisation.
Optimization of frequency and power response.

STABLE DOWN TO 2 OHMS

Huge output power and stable down to 2 OhmsThe power output figures of DP-F series are staggering. The rated power outputs are measured at THD = 1%, continuous sinusoidal 1 KHz with each channel working simultaneously.DP-F amps are also stable down to 2 Ohms. This allows for multiple 8 Ω or 16 Ω speakers to be driven with extreme power.ETHERNET X 2

Control is via the Ethernet network connectors on the front.With the supplied control software all parameters can be edited and all performance functions can be remotely monitored.BUILD YOUR SYSTEM

DP-F and DP-N amps are made for your big line array!With just 3 pcs of DP-4100F or DP-4100N……massive systems can be created.70 V / 100 V READY

In this high impedance system example, the DP-2200F can drive up to 100 pcs of i8T loudspeakers.This configuration can also drive LESS than 100 pcs of i8T. Any number between 2 or 100 !When switched to 100 V mode, DP-N (F) models have Peak Limiter and RMS Limiters set automatically. Only the HPF needs setting in the EQ section.Important : Before connecting the load to the amplifier, first measure the line impedance with an impedance bridge (a simple low-cost unit is adequate). If the load impedance is too low, the power amplifier will be loaded down and may overheat or distort. It’s a myth that you can connect an unlimited number of speakers to a 100 V or 70 V line. If the load impedance measures it’s lower than the amplifier minimum operative impedance, re-tap all the speakers at the next-lower power tap. This raises the load impedance. Measure again.

Why Buy From Marshall Music

At Marshall Music, we’re all passionate and highly experienced musicians that love what we do. Family run and family owned for over 35 years, we stock a huge variety of the very best brands in the world of musical instruments, music technology, professional audio and accessories. At Marshall Music, you’ll get the right advice – exactly what you need to make the best possible purchasing decision. We’ll do all we can to make sure you get the right thing at the right price as efficiently as possible – leaving you with a smile on your face!

Power Output
Stereo power output 8Ω x 2	4 x 650w
4Ω x 2	4 x 1100w
Bridged mono output 16Ω	2 x 1300w
Bridged mono output 8Ω	2 x 2200w
Input sensitivity & Impedance
Sensitivity	selectable 38/35/32/29dB
Balanced XLR input	20KΩ
Max input level	22dBu (9.7Vrms)
Voltage gain	38dB
Slew rate	>50V / μs
Crosstalk	<-90dB
S/N	>107dB
Distortion (1W)	<0.02%
Frequency response
+/-1dB @ 8Ω	20Hz – 20kHz
+/-3dB @ 8Ω	20Hz – 30kHz
Damping factor	>5000
Topology	Class D
Connectors
Signal input	Female XLR jacks
Power output	speakON compatible
Controls
Front panel	AC Switch, 4 x channel gain knobs
Rear panel	Parallel, Stereo & Bridge mode switch, Limiter switch
Protections	Thermal, Over-current, Output DC, Output short
Indicators	Power, Protect, Signal, Limiter
Cooling	Variable speed fan
AC Power	90 ~ 260VAC, 50 ~ 60Hz
Dimensions	44 * 485 * 370mm
Weight (Net)	9.18kg
Weight (Gross)	11.26kg
