Behringer CAT Desktop Duophonic Analog Synthesizer Module
SKU: BEHCATOriginal price was: R9,215.00.R6,915.00Current price is: R6,915.00.
Eurorack-sized Semimodular Analog Synth with 2 VCOs,4 Mixable Waveshapes, Resonant Lowpass Filter, LFO, AR Transient Generator, Poly Chain Compatibility, MIDI In/Thru, and USB-MIDI
In stock
Based on a cult synth classic that prowled onto the scene in the mid-1970s, the Behringer CAT duophonic analog synthesizer has a foreboding growl and a fierce bite owing to its dual-VCO design, four mixable waveforms, and gritty white noise generator. With a sleek interface befitting its name, the CAT takes a straightforward approach to synthesis with a few surprising twists to produce some seriously aggressive synth tones. The CAT’s two analog VCO’s can be independently controlled for laying down fat basslines under sinewy leads in real time or stacked in unison. The CAT lets you blend four variable oscillator shapes — sawtooth, triangle, modulated pulse, and sub-octave square — to produce uber-dense synth tones, which can be further manipulated from six different modulation sources, and a dedicated true-analog sine/squarewave LFO. A self-oscillating-resonant filter and transient generator sharpen the CAT’s fangs by allowing detailed control over its harmonic behavior and envelope generation. Synthesists can’t wait to pounce on the Behringer CAT when it hit our showroom floor. As a standalone semi-modular unit or integrated into a Eurorack system, this swaggering little synth its own pajamas!
Tricks of the Tail
The secret to the CAT’s distinctive sonics is a bevy of unique soundshaping controls. Execute massive one or two octave bends using its Pitch Bend slider control and change the speed of note transitions with the Glide slider. The Cat’s VCA comes equipped with an attack/release transient generator to produce a characterful attack each time you hit a note. With the sample and hold set to noise mode, the CAT spins into chaotic convulsions, perfect for dystopian soundscapes. You can even feed the two oscillators into each other for twisting, evolving waveshapes that will claw out of your speakers.
Eurorack and Poly Chain Compatible
The Behringer CAT can be used as a desktop module or integrated into a Eurorack system and MIDI setup via 5-pin DIN or USB-MIDI. Featuring Behringer’s Poly Chain capability, the CAT is combinable with multiple synthesizers for up to 16 voice polyphony. It also includes an external in, so you can shape and mangle guitars, vocals, drum machines, and more with the CAT’s killer filter and modulators.
Behringer CAT Desktop Duophonic Analog Synthesizer Module:
- Faithful reproduction of a cult classic duophonic analog synth
- Two analog oscillators with four mixable waveshapes — sawtooth, triangle, modulated pulse, and sub-octave square
- Duophonic operation gives you independent key control over the two VCOs
- Two-octave pitch bend slider and glide control with adjustable note transition speed
- AR transient generator adds characterful attack each time a key is depressed
- Gritty white noise generator
- Sample and hold with VCO1 and Noise mode
- Eurorack compatible
- Combine with multiple synthesizers for up to 16 voice polyphony with Poly Chain
- USB-MIDI plus 5-pin DIN In and Thru
- Glide (portamento)
- External audio input
- Low-output and high-output 1/4″ outs
- Behringer’s 3-year warranty
Why Buy From Marshall Music
At Marshall Music, we’re all passionate and highly experienced musicians that love what we do. Family run and family owned for over 35 years, we stock a huge variety of the very best brands in the world of musical instruments, music technology, professional audio and accessories. At Marshall Music, you’ll get the right advice – exactly what you need to make the best possible purchasing decision. We’ll do all we can to make sure you get the right thing at the right price as efficiently as possible – leaving you with a smile on your face!
- Type: Semi-modular Desktop Synthesizer
- Analog/Digital: Analog
- Other Controllers: Pitchbend Slider, Glide Control Slider
- Polyphony: Monophonic, Duophonic and Paraphonic Modes
- Oscillators: 2 x Analog VCO with CAT SRM II Circuitry
- Waveforms: Sawtooth, Triangle, Modulated Pulse, Sub-octave Square
- Noise Generator: White Noise
- Envelope Generator: 2 x Analog EG (ADSR, AR)
- LFO: Sine, Square
- VCA: 1 x Analog VCA
- Filter: 4-pole lowpass (24dB/octave)
- Sample and Hold: Yes
- Analog Inputs: 1 x 1/8″
- Analog Outputs: 2 x 1/4″ TS (main out, low/high), 1 x 1/8″ TR
- Headphones: 1 x 1/8″ TRS (stereo)
- MIDI I/O: In/Out/USB
- Other I/O: 6 x 1/8″ TS CV inputs (VCO 1/2, gate, VCF Fc/q, VCA), 4 x 1/8″ TS outputs (KB CV, gate, ADSR, AR)
- USB: 1 x Type B
- OS Requirements – Mac: OS X 10.6.8 or higher
- OS Requirements – PC: Windows XP or higher
- Power Supply: 12V DC power supply (included)
- Power Usage: 1000mA
- HP Size: 70HP
- Height: 3.66″
- Width: 14.72″
- Depth: 5.35″
- Weight: 3.5 lbs.
