Behringer Edge Analog Semi-Modular Percussion Synthesizer

Controls

The EDGE has a whole slew of modulation and controls that can help you in shaping your beats and basslines and giving them the ability to transcend dimensions or just sound really, really awesome. These include a multi-mode 24 dB resonant ladder filter with a low and high-pass filter and three separate decay envelopes for pitch, filter cutoff and amplitude for detailed control. Thanks to its semi-modular design, the EDGE can perform right out of the box with its default routing. But if you need a lot more control and want to sculpt your sound even more, the EDGE features a 15x 10 I/O matrix for incredibly vast and flexible patching options. The matrix includes inputs for Control Voltages, Decay, Trigger, Velocity, Noise Level, External Audio Sources, Tempo, Modulation and so much more.

The Numbers

The EDGE has 44 controls to give you direct and real-time access to all important parameters, all laid out in a highly intuitive format that puts the fun back in to your beat creation. Input and output connections include MIDI In, MIDI Out/Thru, USB, OSC 1 CV, OSC 2 CV, OSC Decay, ADV/CLOCK, Trigger, Velocity, Noise Level, 1-2FM AMT, EXT AUDIO, Tempo, Play/Stop, VCF MOD, VCF Decay, VCA CV and Pitch. An external MIDI keyboard, footswitch or expression pedal can be connected to the EDGE so you can have even more control over your beats and basslines. If one EDGE isn’t enough for you, you can chain multiple EDGE’s for more intricate combinations.

Unleash Your Creativity

• Analog semi-modular percussion synthesizer for insanely fat music creation
• Pure analog signal path based on authentic VCO and VCF designs
• Dual VCOs with pulse and triangle waves, oscillator sync and FM for a huge range of sounds
• Dual 8-step sequencer with pitch and velocity controls for inspiring grooves and rhythms
• White/pink noise source and external input for unlimited additional timbres
• Multi-mode 24 dB resonant ladder filter with low and high-pass plus cutoff modulation by noise
• 3 separate decay envelopes for pitch, filter cutoff and amplitude for detailed control
• Sequencer speed with up to 10,000 BPM allows for audio range waveform generation
• Semi-modular design with default routings requires no patching for immediate performance
• 15 x 10 I/O matrix for incredibly vast and flexible patching options
• 44 controls give you direct and real-time access to all important parameters
• Multiple clocking sources including MIDI/USB for synchronization with other equipment
• Time division control featuring 8 different rates
• Comprehensive MIDI implementation with MIDI channel and Voice Priority selection
